Digital Clamp Meters

Item Code: DT2003A

Express Function :




General Features :

Item Code: DT2250

Express Function :

Item Code: DT3600

Express Function :




General Features :

Express Function :



General Features :

Features:

. 3½ Digits LCD Max reading 1999
. 5 functions 10 ranges
. Battery check function
. Low battery indication
. Overload protection
. Audible continuity
. Data hold
. Continuity checking with buzzer

Specification:

. DC voltage : 1000V ± 0.8%
. AC voltage : 750V ± 1.2%
. AC Current : 200A ±2.5% 1000A±3.0%
. Resistance : 200Ω / 20KΩ ±1.0%

Accessories :

Test lead; 9V Battery (NEDA 6F22), Users Manual

Features:

. 3½ digits LCD Max. reding 1999
. 5 Functions 9 ranges
. Battery check function
. Low battery indication
. Overload protection

Basic Function
DCV, ACV, ACA

Range: 600V, 600V, 200A, 2A/20A/600A

Beast Avvuracy: ± 1.2% +5
± (1.5 % + 10)
± (2% + 10)
± (3% + 10)
± ( 1.5% + 5)

Resistance :- 2KΩ / 200KΩ/ 2MΩ

Frant Distinguish :- Measure Scope 180V ~ 400V

Continuity :- <50Ω Buzzer sound

Diode Check :- Show just to press to decline approximation open voltage Approx 2.5V

Accessories :- Test lead 1.5V X 2 Battery (AAA)
User`s manual

The unique features of the 40 Mili Amp Measurement

. High precision electric current measurement -0.01A
. High resolution 1.6% high precision measurement
 (many engineers take small measurements more
 often than large current measurements)
. The new clamp head is narrow & the body is
  compact & portable making it ideal for use in
  confined spaces
. Large 1000A AC/DC Current testing: AC/DC
  voltage testing
. Min Max (minimum value / maximum value)
  feature current & voltage modes
. True RMS
. Large back light screen convenient viewing
. 6000 character display
. 4000 Λ resistance measurement
. Continuity testing 30 Λ
. Clamp opening :37 mm

Function Parameter

AC Current
Range : 40.00A , 600.0 A, 1000 A
Resolution : 0.01A , 0.1A , 1A
Accuracy : 1.6% ± 6 digit (50-60Hz) (40A)
2.5% ± 8 digit (60-500Hz) (40 A)
1.5% ± 5 digit (50-60 Hz) (600/1000A)

DC Current
Range : 40.00A, 600.0A, 1000A
Resolution : 0.01A , 0.1A , 1A
Accuracy : 1.6% ± 6 digit (40A) 1.5 % ± 5 digit
(600A)

AC Voltage
Range : 600.0 V
Resolution : 0.1V
Accuracy 1.5% ± 5 digit (20-500Hz)

AC response RMS
DC Voltage
Range : 600.0V
Resolution : 0.1V
Accuracy 1% ± 4 digit

400A AC
3¾ Digit 3999 counts Data Hold APO
Ranges
AC Current:  40A, 400A
Accuracy:  ±(1.5%rdg + 5dgt)
Overload:  400A AC max for 1 min
AC Voltage:  4V,40V,400V,600V (Auto) (50-60 Hz)
Accuracy: ± (1.0%rdg + 3dgt)
Resistance:  400V,4KV,40KV,400KV,4MV,40MV (Auto ranging)
Accuracy: ±(1.0%rdg + 2dgt)
Audible:  50V Approx
Diode Test Functon : 1.0±0.6mA Approx
Power Battery Life : Two 1.5 AAA Batteries 200 hours typical
Dimension : 247 x 76 x 39mm
Weight : 465 gms (Approx)
Accessories : One pair of test leads instruction manual carrying case
Jaw : cable F 43mm (max)
Opening : Bus bar 16mm x 65mm

1000A AC
3¾ Digit 3999 counts Data Hold Frequency Capacitance APO

Range
AC Current : 40A, 400A, 1000A
Accuracy : ±(3%rdg + 4dgt) on 40A
±(2%RDG + 4dgt) on 400A 1000A
Overload : 1000A AC max for 1 min

AC Voltage : 4V,40V,400V,750V (Auto) (40-500Hz)
Accuracy : ±(1.0%rdg + 8dgt) on all ranges except
± (1.5%rdg + 8dgt) on 750V

DC Voltage : 4V,40V,400V,1000V (Auto)
Accuracy : ± (0.5%rdg + 4dgt) on 4V
± (0.7%rdg + 4dgt) on 40V & 400V
± (1%rdg + 4dgt) on 1000V

Resistance : 400V,4kV,40kV,400kV,4MV,40MV (Auto Ranging)
Accuracy : ±(0.7%rdg + 4dgt) on all ranges except
±(1.2%rdg + 4dgt) on 4MV
±(2.5%rdg + 4dgt) on 40MV

Frequency : 10.00Hz, 50,00Hz, 500.0Hz,

Range : 5000KHz, 5000KHz, 5000KHz (Auto)
Accuracy : ±(0.5%rdg+2dgt)
Sensitivity : 3VOverload : 200V DC or AC peak

Duty Cycle : 1% to 99% (Auto)
Accuracy : ±(0.5%rdg+5dgt)

Capacitance : 40nF,40nF,4mF,40mF, 100mF (Auto ranging)
Accuracy : ±(5%rdg+10dgt)

Audible Continuity : 40V Approx

Diode Test Function : 1.0 ± 0.6mA Approx

Power : Two 1.5 AAA Size Batteries

Battery Life : 200 Hours Typical
